Bracket anchor W-KA internally threaded sleeve - CONCSCR-SLEECE-M16AG-DW15-75MM

Bracket anchor W-KA internally threaded sleeve

Bracket anchor W-KA female thread sleeve
CONCSCR-SLEECE-M16AG-DW15-75MM

Art.-no. 5929015075
EAN 4065746385565
All versions

Prices for customers after login

Show availability in Würth branch offices
Exclusively for trade customers

Register now and access more than 60,000 products

For anchoring scaffolding and formwork.

Areas of application:


  • For anchoring scaffolding and formwork

  • The anchor has DIBt National technical approval for use in reinforced or unreinforced normal weight concrete with a concrete compressive strength of min. C20/25 and max. C50/60 in accordance with EN 206:2000-12

  • Anchoring in cracked and uncracked concrete (compression zone)

  • Steel bracket anchor with zinc-flake coating may be used outdoors

Advantages:


  • High loads, minimal spacing and edge distance

  • Small drill hole depth

  • Virtually no expansion effect, enabling minimal edge and axial clearance to be maintained

  • Quick, secure installation by screwing the screw anchor into the drill hole

  • Connection elements are reusable

  • Internally threaded sleeve in base material can be repeatedly used as a fixing point

Technical details:


  • Anchorage via mechanical interlock

  • The saw-tooth threads cut into the concrete when the anchor is screwed into the pre-drilled hole

  • Steel with zinc-flake coating: DIBt National technical approval Z-21.8-2048

  • Transmission of forces in concrete by means of undercut technique in combination with injection mortar
Product information

Würth Catalogue

Datasheets(X)

Certificates/ Documents

 |

 |

Anchor size

22 mm

Anchor length (l)

75 mm

Material

Steel

Surface

Flake zinc

Additional accessory:

Product
Description
Quantity
PU
Price
/PU
Plus Quadro-L Vario hammer drill bit
Plus Quadro-L Vario hammer drill bit

DRL-HAM-PLUS-Q-LV-D22,0-L250-WL200MM

ZEBRA
The perfect solution for reinforcements and hard materials, featuring a symmetrical, one-piece head with four cutting edges and a four-spiral Vario feed helix with core reinforcement
x 1 pcs
1/2 inch socket wrench insert, metric
1/2 inch socket wrench insert, metric

SKTWRNCH-1/2IN-HEXSKT-WS12-L140MM

ZEBRA
Concrete screw mortar WIT-BS For injection system WIT concrete screw
Concrete screw mortar WIT-BS For injection system WIT concrete screw

ANC-MORT-(WIT-BS)-410ML

Also suitable for borehole sealing of concrete screw W-BS
