One-sided hybrid ladder

Hybrid ladder, one-sided with aluminium steps
STANDLDR-HYBRID-2X6-(W.1SD-2ALU-STEP)

Art.-no. 0962934506
EAN 4062856470617

Prices for customers after login

Show availability in Würth branch offices
Exclusively for trade customers

Register now and access more than 60,000 products

Wooden ladder, single-sided with two non-slip 80 mm deep aluminium steps with tested slip resistance for safe and effortless work according to TRBS 2121-2
  • Low weight

  • With finger pinch protection when folding due to 25 mm strut clearance

  • Secure and stable thanks to two round metal rods on each side, which clamp the struts together

  • 80 mm deep aluminium steps with grooved surface, slip resistance class R12 according to DIN 51130

  • Hardwood rungs, double mortised

  • Bucket hook integrated in hinge

  • Transport lock on ladder base
Notice

The aluminium rungs (including fastening material) are included with the ladder and can be fitted in just a few easy steps.

Product information

Datasheets(X)

Certificates/ Documents

 |

 |

Material of beam

Wood

Material of rungs

Wood

Material of steps

Aluminium

Number of rungs

2 x 6

Number of steps

2

Length

1.7 m

Width (bottom)/width (top)

530/340 mm

Rail dimensions

22 mm x 59 mm

Step depth

80 mm

Rung distance

267 mm

Rung dimensions

20 x 50 mm

Stand area according to TRBS 2121-2

Yes

Stride length

1.09 m

Height, vertical

1.6 m

Load capacity

150 kg

Stand height

1.0 m

Working height

2.5 m

Weight

9.8 kg

Standards

EN 131
